Curved With Stainless Steel Strapping

$0.00 – $100.00

Clear

Size & Ventilation?

The hood and ventilation unit are sold separately. We offer a wide variety of ventilation at each hood size, which will automatically populate based on the size you select. We suggest a hood height of 30” – 36” from the cooktop, however, some ventilation systems allow for lower than 30. Please review your local building code prior to making your selections.






Molding


“If “Removed” or “Remove Side Trim” is selected, we will ship pre-cut trim to be installed during installation. Due to the two-piece construction of the hood, trim is necessary to cover seams where exposed.


Crown molding is used to reach the ceiling after installation. Without molding at the top of the hood, there will be a gap between the ceiling and the hood upon completion of the installation. Our crown molding is 3” in width and is installed to cover the gap. If installed in our facility, there will remain a gap between the crown molding and the ceiling.


Comes Loose - Not Installed

Size Modifications


Depth can be increased to fit a variety of insert and liner options not offered by Hoodsly. When selecting an increased depth, it is highly recommended that you select a solid bottom to allow the liner to be fit into place during installation. Dimensions mentioned above are the inside opening depth of the hood, the width remains unchanged.


This can be specific to just VAH and not interrupt the TradeWinds Or Zline


For 8’ ceilings, 30” hood height is recommended, for 9’ ceilings, 36” – 42” hood height is recommended, for 10’ ceilings, 48” hood height is recommended. Please consult your local residential housing code requirements prior to purchasing.

Solid Bottom?

When purchasing a range hood insert / blower from another source other than wholesalewoodhoods.com you may need a solid bottom. Solid bottoms are necessary when the ventilation system used does not match the hood dimensions. The solid bottom will need to be cut out to fit the ventilation system during installation. If a finish is selected, the solid bottom will be finished to match the hood color.


Our normal lead time is approximately 20-24 business days. With rush manufacturing we will build your hood in 15 business days.



Need Some Help?

Call: (877) 847-0405

SKU: N/A Category:

Wholesale Wood Hood’s wood range hoods come in an array of designs and colors to match your kitchen perfectly. The curved with strapping hood is one of our most popular models and is the perfect complement for a trendy, stylish home.  The curved with strapping hood comes in raw, primed/paint ready, or stained/painted. Choose one of our trending colors or match your kitchen with a custom color choice, for an additional fee. Designed to be both elegant and effective, each wood range hood was built with our Proprietary Two-Piece Construction for easy installation, allowing for simple cleaning and easy access to fan and ducting.  Our wood hoods are made from cabinet grade plywood with a white maple veneer.

The stainless steel strapping sits atop our flat molding on the apron and chimney of the hood.  Please note, the number of straps varies based on the width of the hood.

Recommended for use with Zline range hood inserts, Tradewinds hood liners, and Broan for 30″ and 36″ units.

Hood liners and blowers are sold separately and in many cases will ship separately from the wood hood.

Color

Antique White, Black, Blue, Primed/Paint Ready, Raw, White
